UL技术 参数 UL Technical Data | B | C | D |
| 额定电压/电流 Rated Voltage / Current V/A | 300/15 | 300/10 | |
| 压线范围 Wire Range AWG | 16-24 | 16-24 | |
IEC技术参数 IEC Technical Data | |||
| 过电压等级 Overvoltage Category | Ⅲ | Ⅲ | Ⅱ |
| 污染等级 Contamination Class | 3 | 2 | 2 |
| 额定电压/电流 Rated Voltage / Current V/A | 500/32 | 630/32 | 800/32 |
| 冲击电压 Rated Surge Voltage KV | 6 | 6 | 6 |
| 接线截面积 Rated Connecting Capacity mm2 | 1.5 | 1.5 | 1.5 |
材料Material | |||
| 绝缘材料/阻燃等级 Insulation Material / Inflammability Class | PBT/ UL94, V-0 | ||
| 引脚/镀层 Terminal / Plating | Brass / Tin Plated 黄铜/镀锡 | ||
| 螺钉/镀层 Screw / Plating | Steel / Nickel Plated 钢材/镀镍 | ||
其它信息 Other Data | |||
| PCB板孔径 PCB Hole Diameter mm | Φ1.8 | ||
| 剥线长度 Stripping Length mm | 9-10 | ||
| 螺钉/扭力 Screw / Torque /lbf.in | M4/10-12 | ||
